Page 30
22 • Register Format
3.8 Interrupt Status Register
When interrupt occurs, this register provides information for users to
recognize the interrupt status and the interrupt setup condition.
Address: BASE + 0x08
Attribute: Read
7
6
5
4
3
2
1
0
--- --- --- --- ---
CH1 Int.
Status
CH0 Int.
Status
COS
Int.
Status
15
14
13
12
11
10
9
8
--- --- --- --- ---
CH1
Int_EN
CH0
Int_EN
COS
Int_EN
COS Int. Status (bit 0): COS interrupt Status register
0: COS interrupt de-asserts
1: COS interrupt asserts
CH0 Int. Status (bit 1): Digital input channel 0 interrupt status
0: Ch0 interrupt de-asserts
1: Ch0 interrupt asserts
CH1 Int. Status (bit 2): Digital input channel 1 interrupt status
0: Ch1 interrupt de-asserts
1: Ch1 interrupt asserts
3.9 Handling PCI Controller Registers
The PCI bus controller adopted in PCI-7256 is PCI-9030 which is provided by
PLX technology Inc. When users attempt to handle low-level programming,
some registers in PCI-9030 should be noticed. The interrupt control
register(INTCSR; 0x4Ch) of PCI-9030 takes charge of all interrupt
information from local bus to PCI bus. When users want to develop their own
interrupt function driver, both interrupt registers in PCI-9030 and in PCI-7256
have to work together. For more detailed information about the interrupt
control register in PCI-9030, please refer to the PCI-9030 databook.
