2
•
Introduction
The above I/O cards are isolated up-to 5000 Vdc (excluding cables) for
channel-to-computer isolation. It protects your computer against damage
caused by accidental contact with high external voltage and eliminates
troublesome ground loops.
The 743X series products use PCI-9050 PCI controller to interface the board
to the PCI bus. The PCI-9050 fully implements the PCI local bus
specification Rev 2.1. All bus relative configurations, such as base memory
and interrupt assignment, are automatically controlled by BIOS software.
1.1 Features
The PCI-743X Isolated D/I cards provide the following advanced features:
Table 1. Features between different 743X Models
*1: For PCI-7433, cPCI-7433R and cPCI-7432R/P, the isolation
voltage is up to 2500 Vrms.
PCI bus PCI-7432 PCI-7433 PCI-7434
3U CompactPCI cPCI-7432 cPCI-7433
cPCI-7434
cPCI-7434P
3U CompactPCI with Rear I/O
cPCI-7432R
cPCI-7432RP
cPCI-7433R
cPCI-7434R
cPCI-7434RP
32 Isolated Digital Input / Output
Channels
√
-- --
64 Isolated Digital Input
Channels
--
√
--
64 Isolated Digital Output
Channels
-- --
√
High output driving capability
√
--
√
500mA sink current on isolated
output channels
√
--
√
5000 Vrms high voltage isolation
√
*
1 √
*
1 √
Up to 24V voltage protection for
isolated input
√ √
--
External interrupt signal on DI
channels
√ √
--
Dual interrupt trigger
√ √
--
100-pin SCSI-II connector
√ √ √
