Introduction 3
USB-2405
1.4.3 DC accuracy @25°C
1.4.4 AC Dynamic Performance (typical, 25°C)
THD, THD+N (Vin = 8.9 Vpk)
CMRR
Integrated electronic piezoelectric
(IEPE) Current: 2 mA or 0 mA, software
selectable
IEPE compliance: 24V
Over-voltage protection ±60V
Input common mode range ±10V
Trigger source Analog or digital, software selectable
Trigger mode Post trigger, delay trigger, middle
trigger, gated trigger, pre-trigger, post
or delay trigger with re-triggering
Data transfer Programmed I/O, continuous (bulk
transfer mode)
Offset Error (mV) Gain Error (%)
Typical ±0.15mV ±0.15mV
Maximum ±0.3mV ±0.3%
Input Configuration
Input Signal
Frequency (fin)
THD THD+N
Differential 20Hz to 20kHz -94dB -91 dB
20Hz to 46.4kHz -89 dB -88 dB
Pseudo-differential 20Hz to 20kHz -92 dB -88 dB
20Hz to 46.4kHz -85 dB -85 dB
AC (20Hz to 1kHz) 60 dB
