(2) 40-Pin PC/104 Connector Bus C & D
1
2
40
39
40 Pin PC/104 Connector C&D
GND
SBHE
LA23
LA22
LA21
LA20
LA19
LA18
LA17
-MEMR
-MEMW
SD8
SD9
SD10
SD11
SD12
SD13
SD14
SD15
KEY
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C20
--- GND
--- -MEMCS16
--- -IOCS16
--- IRQ10
--- IRQ11
--- IRQ12
--- IRQ15
--- IRQ14
--- -DACK0
--- DRQ0
--- -DACK5
--- DRQ5
--- -DACK6
--- DRQ6
--- -DACK7
--- DRQ7
--- +5 VDC
--- -MASTER
--- GND
--- GND
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
1
2
PC104B
Figure PC104B: 40-Pin PC/104 Connector Bus C & D
3.2.14 Parallel Port Connector (PRIN1)
The connector for the parallel port is a 26 pins female connector.
1
2
26
25
Parallel Port Pin Assignments
PIN DB-25
Signal
PIN DB-25
Signal
1
1
-Strobe
2
14
-Auto Form Feed
3 2
Data
0
4 15
-Error
5 3
Data
1
6 16
-Initialize
7
4
Data 2
8
17
-Printer Select In
9 5
Data
3
10 18
Ground
11 6
Data
4
12 19
Ground
13 7
Data
5
14 20
Ground
15 8
Data
6
16 21
Ground
17 9
Data
7
18 22
Ground
19 10 -Acknowledge 20 23
Ground
21 11
Busy
22 24
Ground
23 12
Paper
24 25
Ground
25
13 Printer
Select 26 -
Not
Used
