9 J7 * 10
J_COM3
1 J10 * 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 N/C
[1]
J_COM4
1 J13 * 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 N/C
[1]
J_COM5
1
J14 *
2
RXD
3
TXD
4
N/C
5
GND
6
N/C
7
RTS
8
CTS
9 N/C
[1]
J_COM6
1 J15 * 2 RXD
3 TXD 4 N/C
5 GND 6 N/C
7 N/C 8 N/C
9 N/C
[1]
10
Notes. These signals are depend on relevant Jumpers (e.g. Pin1 of J_COM1
depends on J6 Jumper), to find more details, check the following table (Location
8~13 & 27~28).
Notes. The pin9 is N/C or 5V or 12V selectable (need corresponding hardware
supported), and the default value is N/C.
8. COM1 Control Jumper（3*2 Pin 2.00mm）
Location Jumper Setting Function
J6
1-2 Pin1: + 5V
3-4(Default) Pin1: DCD
5-6 Pin1: + 12V
