Note. AMB-D255T3 doesn
’t design SATA power connector on the board. Please
use the power supply with SATA power connector for SATA device.
2 ~ 7. COM1~6 Headers（5*2 Pin 2.00mm）
Location Header Pin Definition Pin Definition
J_COM1
1 J6 * 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10
J_COM2
1 J7 * 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
KBMS1
PS/2 Keyboard and Mouse connector
J15
COM6 control jumper
F_USB1
Front USB1 pin header
J_COM1
COM1 pin header
SYS_FAN1
System FAN connector.
PCI1
PCI slot
J_COM2
COM2 pin header
CPU_FAN1
CPU FAN connector
J12 (Reserved)
COM3 control jumper
J_COM3
COM3 pin header
LVDS_P1
LVDS backlight control pin header
J11 (Reserved)
COM3 control jumper
J_COM4
COM4 pin header
ATX1
ATX power supply connector
AUDIO1
Audio connector
J_COM5
COM5 pin header
LVDS1
LVDS pin header
USB2_RJ1
USB2 and LAN1 connector
J_COM6
COM6 pin header
SATA2
SATA2 connector
USB2_RJ2
USB2 and LAN2 connector
J6
COM1 control jumper
SATA1
SATA1 connector
VGA1
VGA connector
J7
COM2 control jumper
LVDS_P2
LVDS VCC selection jumper
LPT1
LPT connector
J10
COM3 control jumper
J_GPIO1
GPIO pin header
HDMI1
HDMI connector
J13
COM4 control jumper
JCMOS1
Clear CMOS jumper
J14
COM5 control jumper
F_PANEL1
Front panel pin header
