AES-HM76Z1FL User Manual
19 www.acrosser.com
3. BIOS Settings
This chapter describes the BIOS setup program. The BIOS settings can be viewed
and changed for the module.
Note: Only technical personnel should change the default BIOS settings.
3.1. Enter the AMI Aptio Setup Utility
Aptio is AMI's BIOS firmware based on the UEFI Specifications and the Intel Platform
Innovation Framework for EFI.
The Aptio Setup Utility can be accessed by pressing the <
Delete> or <Esc> key
during POST.
After powering up, the BIOS message appears on the screen. If the message
disappears before you respond, restart it by pressing < Ctrl> + <Alt> + <Delete>
keys.
3.2. Main Setup
Once you enter the AMI Aptio Setup Utility, the Main Menu appears on the screen.
Press the arrow keys to highlight the item and then press the < Page Up> <Page
Down> keys to select the parameters you want in each item.
Aptio Setup Utility - Copyright © 2012 American Megatrends, Inc.
Version 2.15.1226. Copyright © 2012 American Megatrends, Inc.
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/- : Change Opt.
F1 : General Help
F2 : Previous Values
F3 : Optimized Defaults
F4 : Save & Exit
ESC : Exit
BIOS Information
BIOS Vendor
Core Version
Compliancy
Project Version
Build Date and Time
PCH Information
Intel PCH SKU Name
Processor Information
Intel® Core™ i7-3517UE CPU @ 1.70GHz
Name
Frequency
Processor ID
Number of Processors
Microcode Revision
GT Info
IGFX VBIOS Version
Memory RC Version
Total Memory
Memory Frequency
ME FW Version
ME Firmware SKU
System Language
System Date
System Time
Access Level
American Megatrends
4.6.5.3
UEFI 2.3; PI 1.2
SKU_0 B1.0
07/25/2013 11:22:29
HM76
IvyBridge
1600 MHz
306a9
2Core(S) / 4Thread(s)
16
GT2 (1000 MHz)
2143
1.5.0.0
8192 MB (DDR3)
1333 MHz
8.0.10.1464
1.5 MB
[English]
[Mon 05/06/2013]
[12:03:42]
Administrator
Choose the system default
language.
Main Security Save & Exit Boot Chipset Advanced
