Datalogic Scanning DS1500 User Manual
Page 34
DS1500
2
The Tilt angle is represented by the value T in Figure 17. Position the reader in order
to minimize the Tilt angle.
T
Figure 17 - Tilt Angle
By using the ACB (Advanced Code Builder) software parameter, the tilt angle is less
critical and can be decoded even if the scan line doesn’t cross the entire code.
See par. 3.1 or the Help On Line for details.
22
