Digi FASTTWIST MIL-190C - Manual

Doc #: 90000072 Rev. A
MIL-190C
Fast•Twist
Fast Ethernet Converter
Single-mode Fiber
Installation Guide
This guide includes the following information:
“Introduction” on page 2
“Installation” on page 2
“Diagnostic LEDs and Conditions Indicated” on page 2
“Configuration” on page 3
“RJ-45 Pinouts” on page 3
“Legal” on page 4
5VDC
1 Amp
Ethernet / IEEE 802.3
RX TX
FAST•TWIST
Model MIL•190
100BaseFX
to
100BaseTX
Fast Ethernet
CONVERTER
Single Mode Fiber
POWER
TX ACTIVE FX ACTIVE
SC-Type
Connector
LEDs
Power
Connector
RJ-45
Connector
Phillips-head
Screws
Phillips-head
Screws
