Desa (V)T32EN-A Series - Manual (Page 24)

24
www.desatech.com 116647-01A
Figure 48 - Turning Equipment Shutoff Valve to the OFF Position
Equipment
Shutoff
Valve
Pilot
Adjustment
Screw
LIGHTING
INSTRUCTIONS
NOTICE: During initial operation of new heater, burn-
ing logs will give off a paper-burning smell. Orange
flame will also be present. Open damper or window
to vent smell. This will only last a few hours.
1. STOP! Read the safety information, page 23.
2. Turn off all electric power to the appliance.
3. Turn wall switch to the OFF position.
4. Open lower louver panel.
5. Turn equipment shutoff valve clockwise to the OFF
position (see Figure 48). Do not force.
6. Wait five (5) minutes to clear out any gas. Then smell for
gas, including near the floor. If you smell gas, STOP! Fol-
low “B” in the safety information in page 23. If you donʼt
smell gas, go to the next step.
7. Turn equipment shutoff valve counterclockwise to
the ON position. Do not force.
8. Close lower louver panel.
9. Turn on all electric power to the appliance.
10. Turn the wall switch to the ON position.
11. Visually locate the pilot. The ignitor should begin to spark and
the main burner should ignite once flame appears at pilot.
• If lighting the appliance for the first time each season,
it may take several attempts before the supply gas can
reach the pilot and main burners.
• If the appliance will not stay lit after several attempts,
follow the instructions To Turn Off Gas To Appliance and
call your service technician or gas supplier.
OPERATING FIREPLACE
Lighting Instructions
To Turn Off Gas To Appliance
Optional Remote Operation
Operating Optional Blower Accessory
TO TURN OFF GAS
TO APPLIANCE
1. Turn off the wall switch.
2. Turn off all electric power to the appliance if service is to
be performed.
3. Open lower louver panel.
4. Remove front hearth brick and control access panel.
5. Turn equipment shutoff valve clockwise to OFF.
Do not force.
6. Close lower louver panel.
Figure 49 - Pilot
Sensing Rod
Pilot Burner
Ignitor
OPTIONAL REMOTE
OPERATION
Note: The WRC receiver and hand-held remote control kit
must be purchased separately (see Accessories, page 34). Follow
installation instructions on page 23.
1. Turn equipment shutoff valve to ON position. You can now turn
the burner on and off with the hand-held remote control unit.
IMPORTANT: Be sure to press the ON/OFF buttons on the
hand-held remote control unit for up to 3 seconds to assure
proper operation.
2. Press the ON/OFF button to turn the burner on and off.
OPERATING OPTIONAL
BLOWER ACCESSORY
Locate the blower controls by opening the lower louver panel
on the fireplace. Blower controls are located on the left side of
the switch bracket to the right just inside the louver panel.
The BK manual blower and the BKT thermostatically-controlled
blower have an ON setting and an OFF setting. The blower
will only run when the switch is in the ON position. In the OFF
position, the blower will not operate.
Note for BKT Only:
If you are using BKT blower with optional
thermostat (wall mounted or remote control) for the fireplace,
your fireplace and blower will not turn on and off at the same
time. The fireplace may run for several minutes before the blower
turns on. After the heater modulates to the pilot position, the
blower will continue to run. The blower will shut off after the
firebox temperature decreases.
The blower helps distribute heated air from the fireplace. Peri-
odically check the louvers of the firebox and remove any dust,
dirt or other obstructions that will hinder the flow of air.
OPERATING FIREPLACE
Continued
