PaRTs
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 25 of this manual.
kEY
NO.
PART NUMBER
DESCRIPTION QTY. VF-18N-MHD VF-18P-MHD VF-24N-MHD VF-24P-MHD
1 116950-01 116950-01 116805-01 116805-01 Base 1
2 116853-02 116853-02 116853-01 116853-01 Base Support 1
3 116943-02 116943-01 116810-01 116810-02 Left Burner Bracket 1
4 116951-01 116951-01 116806-01 116806-01 Rear Burner 1
5 116952-01 116952-01 116811-01 116811-01 Pan Burner 1
6 111819-07 111819-11 111819-06 111819-10 Front Orifice 1
7 111819-18 111819-19 111819-16 111819-17 Rear Orifice 1
8 116955-01 116955-01 116815-01 116815-01 Grate 1
9 14391 14391 14391 14391 Venturi Tube 1
10 14527 14527 14527 14527 Burner Gasket 1
11 116807-01 116807-02 116807-01 116807-02 Valve Assembly 1
12 116943-02 116943-02 116816-01 116816-01 Right Burner Bracket 1
13 116854-01 116854-01 116854-01 116854-01 Pilot Bracket 1
14 104285-01 104285-01 104285-01 104285-01 ODS Pilot 1
15 M11084-26 M11084-26 M11084-26 M11084-26 Screw, HWH AB 10-16 x 0.38 27
16 11209 11209 11209 11209 Hex Nut 2
17 112829-01 112829-01 112829-01 112829-01 Air Shutter 1
18 M11084-38 M11084-38 M11084-38 M11084-38 Screw, HWH AB 8-18 x 0.38 1
19 117004-01 — 117004-01 117004-01 Pilot Shield 1
20 099918-03 099918-02 099918-03 099918-02 Burner Regulator 1
21 116957-01 111803-03 116957-01 — Air Shutter 1
22 111824-01 111824-01 111824-01 111824-01 Nut/Sleeve, 3/8" 2
23 111828-01 111828-01 111828-01 111828-01 Nut/Sleeve, 3/16" 1
24 111817-05 111817-05 111817-05 111817-05 3/8" Flextube - 7" 2
25 111817-04 111817-04 — — 3/8" Flextube - 21" 1
— — 111817-09 111817-09 3/8" Flextube - 26" 1
26 111817-03 111817-03 111817-03 111817-03 3/16" Flextube 1
27 14396 14396 14396 14396 Male Adapter Fitting 2
28 117029-01 117029-01 117029-01 117029-01 Female Adapter Fitting 2
29 117030-01 117030-01 117030-01 117030-01 Compression Adapter, Female 2
30 117992-02 117992-02 117026-03 117026-03 Rear Log Kit 1
31 117992-01 117992-01 117026-02 117026-02 Front Log Kit 1
32 117495-01 117495-01 117495-01 117495-01 Caution Decal Bracket 1
33 116673-02 116673-02 116673-02 116673-02 Hand-Held Remote Control 1
34 117307-01 117307-01 117307-01 117307-01 Velcro Strap 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
112796-01 112796-01 112796-01 112796-01 Lighting Instructions Plate 1
100639-03 100639-03 100639-03 100639-03 Caution Decal 1
111288-02 111288-02 111288-02 111288-02 Gas Line Flex with Shut Off 1
117071-01 117071-01 117071-01 117071-01 Control Cover Kit 1
117501-01 117501-01 117501-01 117501-01 5 Piece Scrap Log Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
117685-02 117685-02 117685-01 117685-01 Ember Material 1
** Not a field replaceable part
