SPECIFICATIONS

1500 watts
0.8%

THD

Viper model d2500.1

Signal-to-Noise Ratio

Greater than 80 dB

Frequency Response

20-250 Hz +0, -1 dB

Damping Factor

50 (typical)

Crossover

Low-pass 24 dB/octave,
variable from 30 to
250 Hz

Subsonic Filter

Switchable 24 dB/
octave, variable from
20 to 250 Hz

Bass Equalization

Variable 0 to +12 dB,
centered at 40Hz

Input Impedance

20K ohms

Input Sensitivity

Variable from 150 mV

to 8 volt

Output Impedance

2 to 4 ohms

Supply Voltage

10 to 16 VDC

Fusing and Power

200A

Minimum Cable Requirements (AWG) (+) 12 Volt

#0 Battery to fuse block

(Per amp, trunk mounted)

#4x2 Fuse block to
amplifier

Minimum Cable Requirements (Ground)

#4x2 Amplifier to chassis

2700 watts

2500 watts
1.0%

THD

RMS continuous power driven into 4 ohms from 20 to 250
Hz @ 14.4 VDC at rated power/load.

RMS continuous power driven into 2 ohms from 20 to 250
Hz @ 14.4 VDC at rated power/load.

Dynamic power rating (IHF-202 Standard) minimum load.
