D-Link DES-3216 User Manual
Page 62
10/100 Auto Negotiation Switch User’s Guide
Managing the DES-3216
54
Modify Trunking Port
The Modify Trunking Port panel, displayed in Figure 33, enables you to Modify Trunking
Ports.
Figure 33: Modify Trunking Port
Trunking Port Name
The names of all Trunked Ports appear in this column.
Follow these steps to modify Trunked Ports:
1.
Select the name of the appropriate Trunked Port.
2.
Press Enter.
3.
You will see the Modify Trunking Port panel shown in Figure 33. Use this panel to
modify a Trunking Group.
4.
Select the ports that you want to include in the Trunking Group or delete from the
Trunking Group. Toggle the space bar to change the current setting. Available means the
port is available for inclusion in the Trunking Group. Selected means the port has been
selected as part of a Trunking Group. N/A indicates ports that are not available for
inclusion in any trunking group.
5.
Select Save and press Enter to implement your changes.
