4leds – D-Link DES-3216 User Manual
Page 18
10/100 Auto Negotiation Switch User’s Guide
Managing the DES-3216
10
4
LEDs
The LED panel of the DES-3216, displayed in Figure 4, is designed to allow you to manage
the DES-3216 at a glance. The LEDs indicate the following:
•
Power
•
Speed
•
Link
•
Activity
•
Duplex mode
All of the LEDs are described in detail. Use the tables to determine the meaning of each
LED.
Figure 4: DES-3216 LED Panel
