REPAIR PARTS LIST FOR 15 GALLON SPRAYER MODEL 45-0292
REF.
NO.
PART
NO.
QTY. DESCRIPTION REF.
NO.
PART
NO.
QTY. DESCRIPTION
1 47752 1 Tank (15 Gal.) 40 45029 2 Strainer, Screen Type
2 45015 1 Pump and Motor 41 45037 2 Nut, Screen Body
3 46278 1 Hose, 1/2" ID (24" Lg.) 42 47396 2 Elbow, Plastic 11/16" Thd.
4 45021 1 Hose, 1/2" ID (20" Lg) 43 726-0178 2 Nylon Tie
5 45024 1 Strainer, Cap Type 1" 44 43224 2 Bolt, Hex 5/16-18 x 2-1/4"
6 45031 1 Adapter, 1/2" NPT x Hose 45 46782 2 Bolt, Hex 5/16-18 x 3"
7 45032 3 Nut, Swivel 3/4" Garden Hose 46 43083 6 Nut, Hex 5/16-18 Thread
8 45033 1 Hose Barb, 1/2" 47 44947 4 Bolt, Curved Head 5/16-18 x 1-5/8"
9 45069 4 Screw, Ph. Pan Hd. 10-24 x 1" Lg. 48 43086 16 Lock Washer, 5/16"
10 43910 4 Washer, Flat #10 SAE 49 43343 1 Pin, Hair Cotter #4 (1/8")
11 45084 1 Switch, On - Off 50 R19171616 4 Washer, 17/32" x 1"
12 45082 1 Boot, Rubber Switch 51 44663 2 Hub Cap (1/2" Push Nut)
13 45080 1 Plate, On - Off Switch 52 47623 1 Hitch Pin
14 45048 1 Nut, Hex 15/32-32 Thd. 53 45180 1 Hose Clip, Small
15 45087 1 Bushing, Strain Relief 54 736-0722 2 Lock Washer, #10
16 45085 1 Terminal, .25 Male Tab (not shown) 55 44695 4 Washer, Bowed
17 45086 1 Terminal, .25 Female Tab (not shown) 56 45040 2 Screw, Phillips Hd. #10-24 x 1/2"
18 23889 1 Bracket, Switch Mounting 57 43081 2 Washer, 5/16" Std. Wrt.
19 46276 1 Adapter, 3/4" GH x 1/2" Barb 58 46578 2 Spacer
20 46277 1 Elbow, 3/8 NPT x 1/2" Barb 59 45017 1 Hose "Y" W / Valves 3/4"
21 45025 2 Clamp, 1/2" Hose 60 45071 1 Gauge, Pressure 2" 100 PSI
22 45018 1 Connector with Wire 61 45072 4 Gasket, 3/4" Garden Hose
23 45049 1 Nipple, (Nylon) 1/2" x 3/8" Red. 62 43085 4 Bolt, Hex 5/16-18 x 1-1/2"
24 45050 1 Tee, 1/2" x 1/2" x 1/2" (1/4" Port) 63 44215 2 Bolt, Carriage 5/16-18 x 1-3/4"
25 47406 1 Spray Gun 64 712-0421 2 Knob
26 47393 1 Hose, 1/4" ID (12' 6" Lg) 65 43682 2 Bolt, Carriage 5/16-18 x 1-1/4"
27 45026 6 Clamp, 3/8" Hose 66 43064 4 Nut, Hex Lock 5/16-18 Thd.
28 45034 1 Hose Barb, 3/8" 67 44732 2 Washer, Tooth Lock 5/16"
29 47624 1 Hitch Tube, R.H. 68 47397 1 Hose Clip (Large)
30 47625 1 Hitch Tube, L.H. 69 47390 1 Adapter, 1/2" NPT x 1/4" Barb
31 23014 2 Hitch Bracket 70 47405 1 Clamp, 1/4" Hose
32 24586 2 Clamp, 1/2" Axle 71 47392 3 Hose, 3/8" ID (20" Lg.)
33 24584 1 Axle, 1/2" 72 47399 1 Drain Body
34 47052 2 Wheel 73 47398 1 Washer, Nylon
35 46700 1 Lid 74 47402 1 Nut, Nylon 11/16" Thd.
36 24122 2 Boom Bar 75 47400 1 O-Ring, 5/8" OD
37 24585 1 Bracket, Boom Mount 76 47403 1 Cap, Nylon 11/16" Thd.
38 47394 1 Tee, Plastic 3/8" Hose 47628 1 Owners Manual
39 45028 2 Nozzle, SS Floodjet
