27 106815
OWNER’S MANUAL
KEY PART
NO. NUMBER DESCRIPTION QTY.
ILLUSTRATED
PARTS LIST
For Model RGH11000AIE
Fuel Tank and Roll Cage
This list contains replaceable parts used in
your generator. When ordering parts, fol-
low the instructions listed under Replace-
ment Parts on page 19 of this manual.
1 079503-25AA Gas Tank Assembly 1
2 105905-01 Roll Cage 1
3 105906-01 Axle Mount 1
4 102933-03 Axle 1
5 102932-01 Wheels 2
6 WP-16C Flat Washer, 1" 4
7 C4-12C Cotter Pin 2
8 100135-01 U-Bolt 2
9 NEC-5C Lock Nut, 5/16-18 22
10 WP-5C Flat Washer, 5/16" 30
11 103880-01 Lock Nut, 1/4-20 4
12 WP-4C Flat Washer, 1/4" 8
13 097190-06 Gas Cap w/Fuel Gage 1
14 M51151-02 Fuel Line 1
15 M10990-3 Bushing 1
16 106988-01 Barbed Connector, 1/4" 1
17 25985008 Fuel Line 1
18 105035-01 Handle 2
19 103046-01 Grip 2
20 103057-01 Plug 2
21 H8C5-20C Bolt, 5/16-18 x 2.5" 4
22 099750-01 Bolt, J-Hook 5/16-18 2
23 099749-01 Battery Bracket 1
24 105908-01 Battery Mount 1
25 17529000 Shock Mount 3
26 102962-02 Spreader 1
27 H5C4-24C Bolt, 1/4-20 x 3" 4
28 26302006 Bolt, 1/2-10 x 1" 2
29 WLI-8 Internal Tooth Lockwasher 2
30 14138000 Ground Strap 1
31 M10908-74 Tapping Screw, 1/4-20 x .5" 1
32 WLE-5 External Tooth Lockwasher 1
33 106775-02 Side Panel 1
34 106775-01 Side Panel 1
35 106776-01 Top Cover 1
36 100410-01 Sems Screw, 8-18 8
37 HC5-14C Bolt, 5/16-18 x 1.75" 6
PARTS AVAILABLE NOT SHOWN
099866-05 Safety Information Decal 1
100003-04 Operation Decal 1
099873-01 Battery Cable (Positive, Red) 1
099873-05 Battery Cable (Negative, Black) 1
HC4-6C Screw, 1/4-20 x .75" 2
