Thermal curves – Delta Electronics Series H48SR User Manual
Page 7
DS_H48SR1R860_06272006
THERMAL CURVES
Figure 18:
Hot spot location (unit in mm)
Figure 19:
Output current vs. ambient temperature and air
velocity (Vin=48V / 75V, V
out
=0.8V )
Figure 20:
Output current vs. ambient temperature and air
velocity (Vin=48V / 75V, V
out
=1.8V )
Figure 21:
Power dissipation vs. ambient temperature and air
velocity (Vin=48V / 75V, V
out
=0.8V~1.8V )
7
