SPECIFICATIONS
* Power source
DC 24V & DC 12V. Use power supplies PS-24N & PS-12C or PS-12A.
* Current consumption
0.6A (max.) (without video monitor included).
Less then 0.1 A (standby).
* Wiring
Max. 12 wires & one coaxial cable (to BGR-IOA/MFH-UB/LEF-IOC)
* 4 wires & one coaxial cable (to MFH-UB) (2 unconnected)
* 3 wires (to BGR-lOA)
3 wires & one coaxial cable (to MF-DL) (2 unconnected)
3 wires (to MAW-B relay)
* Wiring distance
■
Between MF-DL & MFW-Pl;
COAXIAL CABLE
DIAM./AWG
5C-2V
0.65 mm
RG-59/U(20GA)
22AWG
DISTANCE
150 m
495'
■
Between MFW-Pl & MFH-UB;
COAXIAL CABLE
DIAM./AWG
5C-2V
0.65 mm
RG-59/U(20GA)
22AWG
DISTANCE
75 m
245'
■
Between MFW-Pl & PS-24N;
DIAM./AWG
1.0 mm
18AWG
DISTANCE
10 m
33'
* Dimensions & weight
(H
X
W
X
D)
190 X 74 X 42 (mm); 7-1/2"
Approx. 270g (0.60 lbs.).
X
2-15/16"
X
1-5/8"
WARRANTY
Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of
one year after delivery to the ultimate user and will repair free of change or replace at no charge, should it become defective
upon which examination shall disclose to be defective and under warranty. Aiphone reserves unto itself the sole right to make
the final decision whether there is a defect in materials and/or workmanship; and whether or not the product is within the
warranty.
This warranty shall not apply to any Aiphone product which has been subject to misuse, neglect, accident, or to use in violation
of instructions furnished, nor extended to units which have been repaired or altered outside of the factory.
This warranty does not cover batteries or damage caused by batteries used in connection with the product.
This warranty covers bench repairs only, and any repairs must be made at the shop or place designated in writing by Aiphone.
Aiphone will not be responsible for any costs incurred involving on site service calls.
