Installation
(It is essential that the machine is
leveled and the locknuts are tight.)
Positioning of the tumbie dryer:
A Free-standing instailation
The dryer can be placed next to a |
washing machine.
Locknut
r--------------
—1
V ]
y
B Built in
The dryer can be built in beneath a
countertop with a height of 331/2-35 1/2'
least 23 5/8" width is needed.
Space must also be available for the exhaust
hose on the left, right or rear of the machine.
At
NOTE:
Height
Adjustment:
321/4-33
1/2".
Do not Raise Higher than 331/22.
4 23/32"
5 1/2" iy
4 1/8"
HQ
I
4 23/32"
i r Diameter of holft
--------- 5/16'
5 5/16"
5 1/2" V'
How much air does the dryer
need?
The dryer needs about 196 cubic yards of
fresh air per hour. The room in which it is
installed must therefore have a sufficient air
change rate to ensure that the machine
receives enough fresh air.
Energy saving hints
• Dry consecutive loads to avoid reheating the dryer.
• Do not overload the dryer.
• Do not put unspun, very wet items in the dryer.
• Clean the lint filter after each load.
• Do not over dry clothes when using the timed program.
• If you plan on ironing items, remove them while still slightly damp.
• Leave the door closed while the dryer is in operation.
