20. Place one 1-1/2" dia. flat washer on axle,
then wheel, one more large flat washer and
secure with cotter pin. See figure 12 and note
below. Repeat step for other wheel.
NOTE
If
cotter
pin
can
not
be
assembled through hole in the
axle ends, remove one washer
from inside, next to sleeve.
MAINTENANCE
1.
Grease or oil wheel bearings occasionally. Use
automotive wheel bearing type grease or 20
weight oil.
2.
Periodically retighten all screws, especially after
heavy use. Do not exceed load capacity rating
of 300 lbs.
3.
Clean cart thoroughly after each use.
4.
Store indoors during severe weather.
5.
Apply light coat of varnish to all wood surfaces
annually.
6.
Use glossy black enamel spray paint to touch-up
scratched or worn paint surfaces.
AXLE
AXLE
SLEEVE
1-1/2" DIA.
LAT WASHER
(INSIDE)
COTTER PIN-
(1) LARGE 1-1/2"
DIA. FLAT WASHER''
WHEEL
(OUTSIDE)
WHEEL
FIGURE 12
21. Turn cart right side up, so that it rests on its
wheels.
22. Place front panel in guides to complete
assembly.
23. Your cart is now ready to use.
