APPENDIX A
TROUBLE SHOOTiNG
PROBLEM
1 SOLUTIONS
LEO fails to light up
Check if power is turned ON or not
Failure of data
transmission
1. Check if the Connector of each cable is well
plugged or not.
2. Check if PC is turned ON o.r not,
3- Check if PRINTER is turned ON or not.
4. Check if paper for PRINTER is well prepared
or not.
5 Check if Print command on PC is correct or
not.
6. Check if connect on computer end has been
connected in accordance with menu,
It failure of printing is still exists upon aforesaid solutions, ptease
contact your dealer for help.
14
User’s Manual
APPENDIX B
CENTROWrCS INTERFACE TIMING CHART
User’s Manual
15
