FUNCTION OVERVIEW AS/2 Auto Switch AS/2 Auto Switch FUNCTION OVERVIEW
1-2 FUNCTJON SPECIFICATIONS
FUNCTIONS
PARALLEL MODEL
AS-401 P ii AS-402PII
Power Supply Non-powered* DC 9V, 200mA
Cable Distance 9M
CONNECTOR
(DB-25)Female
INPUT 4 CENTRONICS
OUTPUT 1 CENTRONICS 2 CENTRONICS
Input Status 4 4
Output Status None 2
LED Printer Ready 1 1
Manual
L
1 1
Buffer Card
(Optional)
256K/1M/2M Bytes
(Support output port #1 only)
Input Arbitration First Come, First Serve
Function Key Manual Select
Input Port Selection Auto or Manual
Output Port Selection None j □ IP SW A AS/2 -WARE
Time out Selection 5 - 60 sec.
Auto Form Feed Enabled/Disabled
Operation Temp. 5"c - 40''c
Stock Temp. -20"c - 60°c
Humidity 0%-80%
Enclosure Plastic and Metal.
Weight iKg
Dimensions 270x145x34.5 mm"
1-3 PRODUCT LIMITATION
AS/2 is a well designed quality product, Its maximum performance and
limitation is described as follows.
AS/2's Manual Switching Mode is suitable for all kinds of Hand­
shaking Modes.
For model AS-402PH and AS-401 P«i, the cable length is limited to no
more than 9 meters
The parallel interface mentioned on this manual are Centronics
interfaces (please refer to appendix 8).
AS/2 is IBM PC/AT/XT compatible.
Buffer card installed In AS-40£Pii is to support output port #1 only.
* AS-401 Pi( needs DC 9V 300mA adapter if buffer card installed,
F|g,-(-2H AS-40lPl|/AS^02PirsFunctiorSpecifications
