POWER ON PROCEDURE
AS/2 Auto Switch
3 POWER ON PROCEDURE
3-1 POWER ON PROCEDURE
1) To reset the AS-402Pii and AS-40lPii (w^buffer card), simply unplug
the DC 9V power adapter from the power jack and plug it ir again.
AS-401PII (w/o buffer card) can be reset by recycling printer power
while it is hooked to a printer.
Caution: Make sure you are using the right power adapter as listed
in the section 1-2 Function Specifications.
2) After power is reset, the input channel's service LEDs are on.
Meanwhile, the AS/2 is ready for operation and it enters the auto
switching mode automatically.
3-2 AUTO SWITCHING MODE
t) In autc switching mode, the user will see all the input channel's service
LEDs turn on, That means the AS/2 stands by to get data from all
channels.
2) If any channel of’CT, C2'.‘C3’ and’C4‘ requests to be served, the
requested channel‘s LEO will be on arKl the AS/2 will lock on to that
channel. At this moment the output port of AS/2 wifi only serve the
locked input chartnel until all the input data from the requested channel
has been sent out arid aiso the time out period is up. The time out
setting depends on the current DiP Switch's Setting on AS/2.
10
User's Manual
AS/2 Auto Switch
POWER ON PROCEDURE
3) When the ‘READY’ LED turns off, it indicates
Connectors are not properly connected,
Prlnier(or output device) is not switched on.
Printer is not in ON-LINE status,
or. Printer is out of paper.
If buffer card installed for output 1 ’READY" LEO reflects buffer
readiness.
The user is therefore requested to make corrections accordingly
before going any further with the procedures,
4) When the AS/2 is serving a certain input channel, it does not switch to
sen/e another channel even though the printing gets interrupted by
the printer power off or out of paper, etc.
NOTE: Only in the ManuaJ Switching Mode user can force the AS/2
to switch to and service another input channel,
3-3 MANUAL SWITCH I MG MODE
Press 'SELECT' several times to instruct AS/2 cycles through
manual switching mode and auto switching modes in the following
sequence: 1-2-3-4-5-1-2-3........
Cycle#
Furclitui
'CVLEO
’C£‘ LED ■C3- LED 04’ LED
MANUAL LED
1
Auto
ON
ON
ON
ON
OFF
2
Manual C/1
ON
OFF
OFF
OFF
ON
3
Manual
OFF
ON
OFF
OFF
ON
4
Manual C#3
OFF
OFF
ON
OFF
ON
5
Manual C#4
OFF
OFF
OFF
ON
ON
Jser's Manual
11
