STACKED INSTALLATION
ASKO dryers can be mounted on top of any matching
ASKO washer. Mounts are supplied with the machine.
The metal brackets are attached to the lower back of the
unit. The plastic cups are packed inside the dryer.
Two metal brackets for
securing the dryer to the
washer
Two plastic cups to
secure the dryer legs.
To install the dryer on top of the washer, follow the steps
below:
1. Remove the two outside screws (20 torx) from the
back of the washer and use them to secure the metal
brackets, as illustrated.
5. Lift the dryer into
position. Raising the
front edge, push the
dryer backwards until
it engages with the
brackets on the back
of the washer.
2. To ensure the dryer is correctly positioned on top of
the washer, align the plastic cups with the front top
edge of the washer.
To position the plastic cups, break off the left tab (A)
on the cup to be placed on the right side of the washer
and break off the right tab (B) on the cup to be placed
on the left side of the washer.
3. Remove the protective
paper from the self­
adhesive surface beneath
the cups. Being careful
not to press the adhesive
surface against the top of
the washing machine, use
the tabs to position the
cups (as illustrated) then
press them firmly into place.
Stacked Installation
Tumble dryer
Washer
Total height 67”.
Adjustable to 69”.
WARNING!
Never stack a washer on top of a dryer!
4. Once the cups are in place, break off the remaining
plastic tabs.
