REPAIR PARTS FOR 48" PLUG AERATOR MODEL 45-0383
Ref.
No.
Part
No.
Qty. Description Ref.
No.
Part
No.
Qty. Description
1 25648 1 48 in. Tray 23 HA21362 9 Hex Nut, 3/8-16 Nylock
2 25800 1 Tongue 24 43501 2 Cotter Pin, 9/64 x 1-1/2 in. Long
3 24619 2 End Plate 25 43012 4 Hex Bolt, 1/4-20 x 3/4 in. Long
4 25665 2 Lift Stop Bracket 26 47189 10 Hex Nut, 1/4-20 Nylock
5 23687 1 Hitch Bracket 27 43054 1 Hex Bolt, 3/8-16 x 2 in. Long
6 25663 1 48 in. Shaft 28 43070 2 Washer, 3/8 in.
7 43009 2 Washer 29 47623 1 Flat Head Hitch Pin, 3/8 in. x 3 in.
8 65337 2 Wheel Bracket Assembly 30 43055 2 Hair Cotter Pin, 3/32 x 1.80 in.
9 24623 1 Middle Brace 31 1509-69 6 Hex Bolt, 1/4-20 x 1-3/4 in. Long
10 65336 1 Lift Bracket Assembly 32 44056 1 Clevis Pin
11 25664 1 Lift Handle 33 43351 1 Hex Bolt, 1/2-13 x 1-1/4 in. Long
12 49791 1 Brace Tube 34 65338 4 Double Spool Assembly
13 R74760884 2 Hex Bolt, 1/2-13 x 5-1/2 in. Long 35 44798 8 Bearing, Flange
14 712-3083 3 Hex Nut, 1/2-13 Nylock 36 26022 32 Aerator Point
15 R19171616 5 Washer, 0.5312 in. 37 43080 32 Carriage Bolt, 5/16-18 x 3/4 in.
16 712-0206 2 Hex Nut 1/2-13 38 43086 32 Lock Washer, 5/16 in.
17 44500 2 Spacer, 1.00 in. Long 39 49798 4 Grease Fitting, 1/4 in.
18 44474 1 Spacer, 2.38 in. Long 40 46503 2 Wheel/Tire Assy., 4.10/3.5-4
19 43182 8 Hex Bolt, 5/16-18 x 3/4 in. Long 41 43943 1 Handle Grip
20 43081 8 Washer, 5/16 in. 42 44593 2 Spacer, 1.75 in. Long
21 47810 40 Hex Nut, 5/16-18 Nylock 49792 1 Owners Manual
22 43001 8 Hex Bolt, 3/8-16 x 1 in. Long
