MAINTENANCE
4
CAUTION
Before inserting the battery pack into the
terminal, ensure the battery polarity matches
with the one indicated within the case.
CONTACTS
Figure 19 Figure 20
CAUTION
When inserting the battery pack, first slide it
towards the springs compressing them until
the contacts at the other end are cleared (see
Figure 18). Then, push downwards to insert
the pack (see Figure 19). Be very careful not
to damage the contacts when pushing
downwards.
4- Close the battery cover and tighten the screws
WARNING
Do not incinerate, disassemble, short terminals or
expose to high temperature. Risk of fire,
explosion. Use specified charger only. Risk of
explosion if the battery is replaced by an incorrect
type. Dispose of the batteries as required by the
relevant laws in force.
