Step 16
• Parts Needed For •
• 6538 Roof Panel (2)
Ridge Caps & Panels
• 6868 Ridge Cap (3)
WP29
1
Install the second
ridge caps 6868
overlapping the first ridge caps while
installing two
roof panels 6538. Hint:
The bolts on the ridge cap need to be
left loose to move the ridge cap to the
side and overlap the ribs of the next
roof panel. Cover the notched areas
ofthe roof panels with strips of weather
stripping tape and continue weather
stripping the ridge.
NOTE
If roof beam holes do not line up
with the roof panel holes, shift the
building from left to right.
If this does not help, your building
may not be level. Shim the
corners until holes line up.
Weather Stripping Tape
6868
6868
