Step 8

• Parts Needed For •

• Rear Wall Channel Assembly (1)

Mid Frames

• Side Wall Channel Assembly (2)

WP21

The mid frame pieces give rigidity to
the side and rear walls.

Fasten the

rear wall channel

across the middle of the rear wall

using screws.

Fasten the

side wall channels

across the middle of the side panels

using screws. Fasten overlaps in
rear corners with bolts and nuts, at

two locations. See the figure.

NOTE

The wall channels behind the

front wall panels will be installed

in a later step.
