VOM-78T OPERATIONS MANUAL
Operation Manual
SPECIFICATIONS:
System
Rated voltage
12 volt DC, negative ground
Operating voltage
10 to 32 volt DC
Current consumption
2.5 amperes
VOM-78T monitor
TV system
EIA
Picture tube
Black and White
7 inch picture measured diagonally
90°degree deflection angle
Picture image
Factory preset to reverse image
Picture resolution
600 TV lines
Power connector
Red : Positive input (10V to 32V)
Blue : Reverse gear input (12V or 24V)
Black: Ground
Inputs
4-pin minijack
1) Video input: 1,0V p-p Sync. Negative
2) 12V Tilt control power (CA1 only)
3) Audio input
4) 12V, 0.2A DC (output)
5) Shield Ground
Power requirements
10V to 32V DC
Power consumption
20W Maximum
Operating Temperature Range
-15°C to + 50‘C (+5°F to +122° F)
Storage Temperature Range
-25°C to + 85°C (-13°F to +185°F)
VOM-78T 13
