C Y RAQ™ 21 CyberResearch
® Displays
Dimensions
Width 19.02" (483 mm)
Height 15.71" (399 mm)
Depth 3.1" (79 mm)
Width, Rack-Mount EIA standard 19 inches at flanges
Height, Rack Units 9U (15.75")
Depth Behind Panel 1.5" (38 mm)
Depth In Front of Panel 1.6" (41 mm)
Max Protrusion from Panel (w/installed gasket) 1.7" (43 mm)
Panel-Mount Cutout, Width 17.3" (440 mm)
Panel-Mount Cutout, Height 14.0" (356 mm)
Maximum Panel-Mount Cutout Depth .55" (14 mm)
Dimension Details
•
Bezel Depth in Front of Panel: 1.6" +
gasket thickness
• Gasket Depth: 0.125" uncompressed.
• Mounting Adapter Plate Depth: 0.1"
• Rack Height in Portrait View: 19.2"
(11U)
Weight
Weight 24.03 lbs (10.9kg )
Display Filter Weight Under 30 lbs.
