Guidelines for Operating the Viewing Angle of LCD Monitor
INTRODUCTION
Height Adjustment
You can adjust the height of the
monitor by securely holding the base
with one hand and pulling up the
monitor stand with the other. The
height of the monitor can be be
adjusted from 403.5mm to 525mm.
1
^ d
Backward/Forward Angle Adjustment
The vertical angle of the monitor can
be adjusted 3 degrees forward and 35
degrees backward by holding the
monitor support at the top and moving
the
monitor
screen
forward
backward from the bottom.
TV
p
I
m
I 3' Typical 3ST
or
Rotate
The monitor screen can be swiveled
left or right by holding the monitor
support at the top, grabbing the edge
of the screen and turning it to face 35
degrees left or right.
Pivoting
Grab the opposite corners and rotate
the screen 90 degrees.
7
♦ ♦ ♦
