PARTS LIST FOR MODEL 114-530A
REF.
NO. PART
NO. DESCRIPTION
NEW
PART
1 710-117 Hex Scr. 5/16-24 x 1.00" H.T.
2 710-158 Hex Scr. 5/16-24 x 1.25" Lg.*
3 11993 Frame Ass'y.
4 710-209 Hex Sems Scr. %-16 x .62" Lg.*
5 710-567 Hex Sems Scr. 'A-28 x %" Lg.
6 712-107 Hex Cent. L-Nut L4-20
7 11650 Deck Ass'y.—22 in.
8 11193 Protective Shield Ass'y.—Comp.
9 718-132 Oil Cap
10 741-113 Ball Brg. .504 I.D. x 1.38 Dia.
1 1 738-114 Should. Scr. .498" Dia. x 4.755"
12 11679- -458 Chute Deflector Ass'y.
13 732-253 Torsion Spring
14 726-106 Push Cap
15 11130- -458 Adapter Plate
16 711-555 Pivot Pin
17 10769 Blade Adapter Kit
18 734-439 16" Rear Wheel Ass'y.—Comp.
19 734-180 16" Rear Wheel—Less Tire
734-392 Semi Pneumatic Tire 16 x 1.75
20 741-178 Ball Brg. .38 I.D.
21 710-427 Hex Scr. %-16 X 2.00" Lg.* N
22 734-642 Front Wheel Ass'y. Comp. N
23 736-105 Belleville Washer
24 738-251 Blade Spindle N
25 714-365 #6 Hi-Pro Key 5/32 x %" Dia.
26 712-123 Hex Nut 5/16-24 Thd.*
27 736-119 L-Wash. 5/16" Scr.*
28 742-125 22" Blade
29 710-117 Hex Scr. 5/16-24 x 1.00" H.T.
30 710-459 Hex Scr. %-24 x 1.50" Lg. H.T.
31 736-217 Spring L-Wash. %" Scr. H.D.
32 7919 Scalp Plate
33 10769 Blade Adapter Kit
34 712-123 Hex Nut 5/16-24 Thd.*
35 736-119 L-Wash. 5/16" Scr.*
36 712-123 Hex Nut 5/16-24 Thd.*
37 736-119 Spring L-Wash. 5/16" Scr.*
38 712-123 Hex Nut 5/16-24 Thd.*
39 12281 Blade Reinforcement Plate N
40 712-123 Hex Nut 5/16-24 Thd.*
41 736-119 L.-Wash. 5/16" Scr.*
42 8253 Bearing Housing
43 741-919 Ball Bearing
44 8253 Bearing Housing
45 7ft5-192 Truss Hd. Mach. Scr. 10-24x.38 Lg.
46 8295--458 Blade Spindle Cover
47 712-526 Speed Nut #10-24
48 11679- -458 Chute Deflector Ass'y.—Comp.
*For faster service obtain standard nuts and bolts iocaüy. If these items
cannot be obtained locally, order by part number and size as shown
on the parts list.
(453 __ Arctic Blue) When ordering parts, if color or finish is important, use the appropriate
color code shown at left. (e.g. Arctic Blue—11815 (458)
The engine is not under warranty by the mower manufacturer.
If repairs or service is needed on the engine, please contact
your nearest authorized engine service outlet. Check the "Yellow
Pages" of your telephone book under "Engines—Gasoline."
13
