Battery Packs
Your tool uses a 12.0 Volt a 14.4 Volt or an 18.0 Volt B&D battery pack. When
ordering replacement battery packs, be sure to include catalog number and
voltage: (12.0 Volt - 97150,14.4 Volt - 97152 or 97153,18.0 Volt 97156)
XR PACK™ Extended Run-Time battery packs deliver 25% more run-time
than standard battery packs.
NOTE:
Your tool will accept either standard or
Extended Run Time battery packs. However, be sure to select proper voltage.
Chargers 98014, 97014, 97015, 97016, 98020
Cat No.
Charging a
Standard Pack
Charging a
1.7 Amp hourXRPACIT«
Volts
98014
60 minutes
75 minutes
12.0,14.4
97014
45 minutes
60 minutes
12.0,14.4
97015
40 minutes
50 minutes
12.0,14.4
98020
15 minutes
15minutes
12.0,14.4
97016
40 minutes
50 minutes
18.0
Your battery can be charged in the
98014, 97014
(1 Hour Chargers), the
98020
(15 Minute Charger), or the
97015
or
97016
Charger. (NOTEiOnly the
97016 will charge 18.0V batteries.) Be sure to read all safety instructions
before using your charger.
Charging Procedure
These chargers require no adjustment and are designed to be as easy as
possible to operate. Simply place your battery pack into the receptacle of a
plugged in charger (FIG.1) and it will automatically charge the pack.
98014/97014(1 Hour Chargers)
1. Plug the charger into an appropriate AC power outlet.
2. Insert the battery pack into the charger, as shown in FIG.1, making sure
the pack is fully seated in the charger. The red (charging) light will blink
continuously indicating that the charging process has started.
3. The battery pack will be fully charged in about 1 hour. The completion of
charge will be indicated by the red light remaining ONcontinuously. The
pack is fully charged and may be used at this time or left in the charger.
98020 (15 Minute Charger)
1. Plug the charger into an appropriate AC power outlet. The charger will
beep twice, the red light will blink and go off.
2. Insert the battery pack into the charger, as shown in FIG. 1, making sure
the pack is fully seated in the charger. The red light will blink and the
charger will beep once indicating the charging process has started.
3. The battery pack will be fully charged in less than 15 minutes under most
conditions. This will be indicated by the red light remaining ON and 3
beeps. The pack is fully charged and may be used at this time or left in the
charger.
Weak Battery Packs (98020).
The charger can also detect a weak battery.
Such batteries are still usable but should not be expected to perform as
much work. In such cases, about 10 seconds after battery insertion, the
charger will beep rapidly 8 times to indicate a weak battery condition. The
charger will then go on to charge the battery to the highest capacity possible.
97015/97016
1. Plug the charger into an appropriate AC power outlet.
2. Insert the battery pack into the charger, as shown in FIG. 1, making sure
the pack is fully seated in the charger. The red (charging) light will blink
continuously indicating that the charging process has started.
3. The completion of charge will be indicated by the red light remaining ON
continuously. The pack is fully charged and may be used at this time or
left in the charger.
Leaving the battery pack in the charger:
When the red light remains ON, the
