MAINTENANCE SPECIFICATIONS
Cleaning the front panel
When the front panel is soiled, wipe the surface
of the panel with a dry and soft cloth.
Cleaning the tape head
Use a cleaning cassette to clean the playback
head and capstans approximately once a month.
If the playback head is dirty, the high tones may
not be reproduced properly.
Cleaning the connector
The connector on the reverse side of the front
panel needs to be cleaned occasionally. Wipe
the surface of the connector with a cotton swab
slightly moistened with alcohol.
RADIO SECTION
(FM)
Frequency Range: 87.5 MHz-108 MHz
(lOO-kHz steps)
87.5 MHz-108 MHz
(50-kHz steps)
Usable Sensitivity: 12.7dBf
50 dB Quieting Sensitivity:
17.2 dBf
iF Rejection: 80 dB
Frequency Response: 30 Hz-15,000 Hz
S/N Ratio: 63 dB
Stereo Separation: 35 dB at 1 kHz
Aiternate Channei Seiectivity:
70 dB
Capture Ratio: 3 dB
(AM)
Frequency Range:
Usabie Sensitivity:
TAPE SECTION
Wow/Fiutter:
Tape Speed:
S/N Ratio:
Frequency Response: 40 Hz-14,000 Hz
530 kHz-1,710 kHz
(10-kHz steps)
522 kHz-1,620 kHz
(9-kHz steps)
30 pV (30 dB)
0.1% (WRMS)
4.8 cni/sec. (1 % ips)
50 dB
Stereo Separation:
FF/REWTime:
40 dB
190 sec. (C-60)
AUDIO SECTION
Max. Power Output: 35 W X 4 channeis
CD IN input
Input sensitivity (load impedance)
COIN: 500 mV (10 kn)
GENERAL
Power-Supply Voltage:
14.4 V (11 to 16 V allowable),
DC, negative ground
4£2
Bass ± 10 dB at 100 Hz
Treble ± 10 dB at 10 kHz
Preamp Output Voltage (load impedance):
2.2 V (10 ki2)
Installation size: 182 (W) x 53 (H) x
155 (D) mm
(7 V4 (W) X 2 V b (H) X
6 V b (D) inches)
Accessory supplied: Carrying case (1)
• Specifications and external appearance are subject to
change without notice due to product improvement.
Load Impedance:
Tone Control:
ENGLISH
