2. Electrical Service Specifications
ADG-78 (Gas)
ADS-78 (Steam)
E
l e c tr ic
S
e r v ic e
S
p e c ih c a t io n s
(per dryer)
IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME When orderinfi. snecifv exact voUaee.
NOTE: A. Fuse ratings are dual-element time-delay, current Hmiting. class RKl or RK5 №JLY.
B. Qicuit breakers are thennal magnetic (industrial) type (WLY. For others, calculate/verify correct breaker size
according to apjAiance amp draw rating and type of breaker used.
C. Circuit breakers for 3-phase dryers must he 3-pole type.
SERVICE
WIRE
APPROX.
MINIMUM
FUSING
cm curr
PHASE
Dual Element
Time Delay
VOLTAGE
SERVICE
AMP DRAW
WIRE SIZE*
BREAKER
120
10
2
13
#10
20
25
208
10
2
8
#14
12
15
208
30
3
5
#14
8
15
230
10
2
7
#14
12
15
230
30
3
5
#14
8
15
240
10
2
7
#14
12
15
380-400
30
3
3
#14
5
15
416
30
3
3
#14
5
15
460
30
3
3
#14
5
15
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that
is affixed to the back of the dryer, at the upper right hand comer. In the case of
208 VAC or 230/240 VAC, the supply voltage must match the electric service
specifications of the data label exactly.
I IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC and 230/240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically VOID THE
WARRANTY.
NOTE: For electrically heated and steam models, contact the factory for electrical service
specifications.
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
