Model 070 Electric
PARTS LIST FOR MODEL 070 ELECTRIC ROTARY MOWER
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 15866 20" Deck Ass’y. 28 750-0515 Spacer .511" I.D. x .70" O.D.
2 718-0145 Grip
X
.38" Lg.
3
—
120V Electric Motor 29 710-0888 Hex Bolt 5/16-24 x 1.00" Lg.
Briggs & Stratton 101120 (Grade 5)
4 731-0655 Motor Shroud 30 710-0157 Hex Bolt 5/16-24 x .75" Lg.
5 734-0840 Wheel Ass’y- Comp. 7 x 1.50 31 712-0123 Hex Nut 5/16-24 Thd.*
6 742-0123 20" Blade 32 736-0119 L-Wash. 5/16" I.D.*
7 749-0373 Lower Handle 33 736-0242 Bell-Wash. .345" I.D. x .88"
8 749-0571 Upper Handle O.D.
9 15549 Drive Housing Brkt.—L.H. 34 753-0351 Blade Adapter Kit
10 710-0253 Hex Bolt 3/8-16 X 1.00" Lg.* 35 15870 Chute Deflector Ass’y. Comp
11 710-0901 Hex Wash. Hd. “F” Tap Scr. 36 11130 Deflector Hinge Plate
#10-32
X
.314" Lg. N 37 711-0555 Hinge Pin
12 710-0597 Hex Bolt 1/4-20 X 1.00" Lg.* 38 732-0253 Torsion Spring
13 712-0798 Hex Nut 3/8-16 Thd.* 39 726-0106 Push On Flange Nut
14 736-0169 L-Wash. 3/8" I.D.* 40 710-0289 Hex Bolt 1 / 4-20 X
.50" Lg.*
15 712-0798 Hex Nut 1/4-20 Thd.* 41 712-0287 Hex Nut 1 / 4-20 Thd.*
16 736-0329 L-Wash. 1 / 4 " I.D.* 42 736-0329 L-Wash. 1 / 4 " I.D.*
17 725-0898 Control w/Cord 43 712-0267 Hex Nut 5/16-18 Thd.*
18 725-0908 Cord Restraint 44 736-0242 Bell-Wash. .345" I.D. x .88"
19 14836 Retaining Strip O.D.
20 710-0776 Hex Wash. Hd. AB-Tap Scr. 45 738-0296 Shid. Bolt .437" Dia. x .268"
1/4 X
.62" Lg.
Lg.
21 731-0575 Rear Flap Ass’y. 4.65 x 17.2" 46 710-0671 Curved Hd. Carr. Bolt 5/16-18
Lg. X 1.38" Lg.
22 712-0798 Hex Nut 3/8-16 Thd.* 47 712-0267 Hex Nut 5/16-18 Thd.*
23 736-0105 Bell-Wash. .400" I.D. x .88" 48 736-0119 L-Wash. 5/16" I.D.*
O.D. 49 726-0223 Cable Tie
24 738-0213 Shid. Bolt .498" Dia. x 1.450" 50 736-0331 Bell-Wash. .39" I.D. x 1.13"
Lg. O.D.
25 712-0798 Hex Nut 3/8-16 Thd.* 51 725-0899 Restraint
26 736-0105 Bell-Wash. .400" I.D. x .88" 52 731-0564 Plastic Plug
O.D. 53 710-0725 Truss Mach. AB-Tap Scr.
27 738-0509 ShId. Bolt .498" Dia. x 1.830"
Lg.
*For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
NOTE: The motor is not under warranty by
the mower manufacturer... If repairs or
service is needed on the motor, please
contact your nearest Briggs
and Stratton authorized en­
gine service outlet. Check the
“Yellow Pages” of your tele­
phone book under “Engines—
Gasoline.”
Find It Fast
In The
Yellow Pages
NOTE
Specifications subject to change without
notice or obligation.
11
