B-7
Catalyst 2900 Series XL Hardware Installation Guide
78-6461-03
Appendix B Connectors and Cable Specifications
Connecting to a Terminal
Connecting to a Terminal
Use the thin, flat, RJ-45-to-RJ-45 rollover cable and RJ-45-to-DB-25 female DTE
adapter to connect the console port to a terminal.
Table B-3 lists the pinouts for
the console port, the RJ-45-to-RJ-45 rollover cable, and the RJ-45-to-DB-25
female DTE adapter.
Note The RJ-45-to-DB-25 female DTE adapter is not supplied with the switch. You
can order a kit (part number ACS-DSBUASYN=) containing this adapter from
Cisco.
Table B-2 Console Port Signaling and Cabling Using a DB-9 Adapter
Console
Port (DTE) RJ-45-to-RJ-45
Rollover Cable RJ-45-to-DB-9
Terminal Adapter Console
Device
Signal RJ-45 Pin RJ-45 Pin DB-9 Pin Signal
RTS 1 8 8 CTS
Not connected 2 7 6 DSR
TxD 3 6 2 RxD
GND 4 5 5 GND
GND 5 4 5 GND
RxD 6 3 3 TxD
Not connected 7 2 4 DTR
CTS 8 1 7 RTS
