Figure 2-7 – Cisco 2900 SERIES XL User Manual
Page 57
2-15
Catalyst 2900 Series XL Hardware Installation Guide
78-6461-03
Chapter 2 Installation
Installing the Switch in a Rack
Figure 2-7
Attaching Brackets on Catalyst 2912MF XL and 2924M XL Modular
Switches (Rear-Panel Forward)
DC INPUT
RATING
100-120/20
0-240V
2.0A/1.0A 5
0-60HZ
~
DC INPUT
RATING
100-120/20
0-240V
2.0A/1.0A 5
0-60HZ
~
47299
19" configuration
23" and 24" configuration
Phillips
flat-head
screws
Phillips
truss-head
screws
