MOUNTING
BOLT
COTTER PIN
CASTLE NUT
BELLEVILLE
WASHER
FIGURE 15.
Set edger back on its wheels. Replace spark plug
wire.
OFF-SEASON STORAGE
The following steps should be taken to prepare unit
for storage.
1. Clean and lubricate unit thoroughly.
2. Refer to engine manual for correct engine storage
instructions.
3. Coat unit's cutting blade with chassis grease to
prevent rusting.
4. Store unit in a dry, clean area.
A CAUTION
When storing any type of power
equipment in an unventilated or metal
storage shed, care should be taken to
rust proof the equipment. Using a
light oil or silicone, coat the equip
ment, especially springs and bearings.
TROUBLE SHOOTING CHART
PROBLEM
CAUSE
REMEDY
1. Engine Fails
to start.
A. Check fuel tank for gas.
B. Spark plug lead wire,
disconnected.
C. Faulty spark plug.
A. Fill tank if empty,
B. Connect lead wire.
C. Spark should jump gap between control electrode and side
electrode. If spark does not jump, replace the spark plug.
2. Hard Starting
or loss of power.
A. Spark plug wire loose.
B. Dirty air cleaner.
A. Connect and tighten spark plug wire.
B. Clean air cleaner as described in engine manual.
3. Engine Over
heats.
A. Carburetor not adjusted
properly.
B. Air flow restricted.
C. Engine oil level low.
A. Adjust carburetor. See engine manual.
B. Remove blower housing on engine and clean as described in the
engine manual.
C. Fill crankcase with the proper oil.
4. Excessive
vibration at
blade.
A. Spindle bolt bent.
B. Ball bearing worn out.
A. Replace spindlebelt .
B. Replace ball bearing.
• 5. Belt Slips.
_____________________
A. Belt worn or stretched.
B. Cl^utch handle will not
remain in clutch plate.
A. Replace bolt.
B. Readjust spring tension at clutch handle.
NOTE; For repairs beyond the minor adjustments listed above, please contact your local service dealer.
