Models 402, 404 and 405
PARTS LIST FOR MODELS 402, 404 AND 405 ROTARY TILLERS
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
710-0528
Hex Bolt 5/16-18
X
VA"
Lg.*
51
726-0175
Clamp 5/16" Dia.
2
720-0180
Grip
52
736-0119
L-Wash. 5/16" I.D.*
5
710-0458
Carr. Bolt 5/16-18 x 1.75"*
53
712-0267
Hex Nut 5/16-18 Thd.*
7
784-0031
Clutch Grip Ass’y—L.H.
54
710-0118
Hex Bolt 5/16-18
X
3/4" Lg.*
(Tines)
55
720-0165
Ball Knob
VA" Dia.
9
15093
Ciutch Cable Bracket
56
736-0169
L-Wash. 3/8" I.D.*
10
710-0607
Hex Wash. S-Tap Scr.
57
712-0798
Hex Nut 3/8-16 Thd.*
5/16-18
X
.62" Lg.
58
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
11
712-0256
Hex Nut 5/16-24 Thd.
59
15393
Brkt. Reinforcement (404, 405)
12
736-0119
L-Wash. 5/16" I.D.*
784-0087
Brkt. Reinforcement (402)
13
746-0484
Wheel Drive Cable
60
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
14
712-0267
Hex Nut 5/16-18 Thd.*
61
784-0026
Tine Shield Ass’y. (405)
15
736-0119
L-Wash. 5/16" I.D.*
14987
Tine Shield Ass’y. (404)
16
784-0036
Handle Panel
784-0085
Tine Shield Ass’y. (402)
17
749-0639
Handle—L.H. (402, 404)
62
714-0149
Hairpin Cotter
749-0637
Handle—L.H. (405)
63
711-0415
Clevis Pin 3/8" Dia.
18
712-0798
Hex Nut 3/8-16 Thd.*
64
749-0762
Handle—R.H. (405)
19
736-0169
L-Wash. 3/8" I.D.*
749-0763
Handle—R.H. (402, 404)
20
736-0105
Bell-Wash. 3/8" I.D.
65
720-0195
Hand Knob (405)
21
710-0253
Hex Bolt 3/8-16
X
1.00" Lg.*
66
714-0127
Cotter Pin 1/16" Dia. x .75"
22
714-0507
Cotter Pin 3/32" Dia. x 3/4"*
Lg.* (405)
23
725-0157
Cable Tie
67
712-0375
Hex Cent. L-Nut 3/8-16 Thd.
24
747-0432
Tiller Flap Rod (404, 405)
(405)
747-0501
Tiller Flap Rod (402)
68
784-0270
Clutch Grip Ass’y.—R.H.
25
14989
End Cover Ass’y-—L-H.
(Wheels)
14990
End Cover Ass’y.—R.H.
69
738-0560
Shoulder Bolt .38" Dia. x
(Not Shown)
1.53" Lg.
26
736-0242
Bell-Wash. 5/16" I.D.
70
741-0402
Hex Flange Plastic Bearing
27
712-0267
Hex Nut 5/16-18 Thd.*
71
738-0561
Shoulder Nut V4-20 Thd.
28
15390
638 Side Shield
72
746-0502
Throttle Control Wire (404,
29
15397
L.H. Tine Ass’y. Comp.
405)
(404, 405)
746-0512
Throttle Control Wire (402)
15398
R.H. Tine Ass’y. Comp.
73
831-0823
Throttle Control Box Ass’y.
(404, 405) (Not Shown)
74
736-0219
Bell-Wash. .40" I.D. (405)
784-0083
L.H. Tine Ass’y. Comp. (402)
75
784-0022
Handle Pivot Bracket (405)
784-0082
R.H. Tine Ass’y. Comp. (402)
76
738-0281
Shoulder Bolt (405)
(Not Shown)
77
784-0019
Handle Mtg. Bracket (405)
30
712-0241
Hex Nut 3/8-24 Thd.*
78
784-0025
Adj. Handle Ass’y. (405)
31
736-0169
L-Wash. 3/8" I.D.*
79
712-0375
Hex Cent. L-Nut 3/8-16 Thd.
32
710-0191
Hex Bolt 3/8-24 x 1.25" Lg.*
(405)
33
714-0149
Hairpin Cotter
80
736-0105
Bell-Wash. .40" I.D. x .88"
34
14978
Tine Adapter Ass’y. (404, 405)
O.D.(405)
784-0084
Tine Adapter Ass’y. (402)
81
736-0253
Bell-Wash. Vz" I.D.
X
1.00"
35
742-0106
Tine 12" R.H.
O.D.(405)
36
742-0105
Tine 12" L.H.
82
711-0765
Lock Pin 5/16" Dia. x 8" (405)
37
711-0415
Clevis Pin 3/8" Dia.
83
784-0023
Lower Sliding Ass’y. (405)
38
712-0267
Hex Nut 5/16-18 Thd.*
84
736-0463
FI-Wash. .291" I.D. x .62"
39
736-0119
L-Wash. 5/16" I.D.*
O.D.(405)
40
14979
Tine Shield Flap (404, 405)
85
732-0145
Compression Spring .36"
784-0088
Tine Shield Flap (402)
O.D.
X
1.00" Lg. (405)
41
710-0736
Hex Bolt 5/16-18
X
1.0" Lg.*
86
738-0147
Shoulder Bolt Vz" Dia. x
42
738-0507
Shid. Bolt Vz" Dia. x .426"
.170" Lg. (405)
43
736-0117
FI-Wash. 3/8" I.D. x 5/8" O.D.
87
710-0599
Hex Wash. S-Tap Scr. V4-20
44
710-0216
Hex Bolt 3/8-16
X
3/4" Lg.*
X
.50" Lg.
45
14992
Depth Bar Ass’y.
88
736-0242
Bell-Wash. 5/16" I.D.
46
712-0267
Hex Nut 5/16-18 Thd.*
89
736-0285
FI-Wash. 5/8" I.D. (405)
47
736-0119
L-Wash. 5/16" I.D.*
90
710-0779
Self-Tap Scr. #10 x Vz" Lg.
48
712-0267
Hex Nut 5/16-18 Thd.*
91
746-0484
Tine Control Cable (402, 404)
49
736-0119
L-Wash. 5/16" I.D.*
746-0535
Tine Control Cable (405)
50
14975
638
Frame Rail—L.H.
