Generac NP-50G Recreational Vehicle Generator
Drawing No. 92200
REPAIR PARTS - ENGINE ACCESSORIES
ITEM
DESCRIPTION
PART NO.
QTY.
ITEM
DESCRIPTION
PART NO. QTY.
1
Intake Manifold
90896
1
28
Choke Linkage
91642
1
2
Manifold Head Gasket
91039
1
29
Cotter Pin
36544
1
3
M6-1.0
X
20 Capscrew &
68527
2
30
Choke Heater Assy.
89473
1
Lock Washer Bolt
31
#4-40
X
.19 Phillips Screw
47488
4
4
#RC12YC Champ Spark Plug
72347
1
32
#4 Lock VVasher
22159
4
5
Carb./Manifold Gasket
89228
1
33
#4 Flat Washer
31879
4
6
Carburetor
91188A
1
34
M5
X
10 Taptite Screw
74908
2
7
Carb./Air Filter Gasket
90970
1
35
Choke Assy. Cover
91677
1
8
Air Filter Base
73108
1
36
Rubber Grommet
22717A
1
9
Carb. Shield Plate
91204
1
37
#8
X
.37 Crimptite Screw
63036
1
10
#8
X
.37" Plastite Screw
59635
4
38
Summer/Winter Decal
92252
1
11
M6
X
12 Capscrew &
66476
2
39
Gov. Spring Adj. Brkt. Assy.
92164
1
Lock Washer Bolt
40
M8
X
15 Taptite Bolt
83512
2
12
80 Lg. Carb. Mount. Bolt
92695
2
41
M5-0.8 Locking Nut
83503
1
13
Air Filter
73111
1
42
Gov. Arm Lever
90968
1
14
Air Filter Pre-Cleaner
81646
1
43
M6
X
30 Washer/Lock
83532
1
15
Air Filter Cover
73104B
1
Washer Bolt
16
Air Filter Cover Bolt
78609
2
44
M6 Special Nut
86681
1
18
NP-50G (360 Eng. only)
91554
1
45
Governor Spring
91638
1
A/C Data Decal
46
Gov. Rods Bellcrank
91633
1
NP-50G (410 Eng. only)
91554B
1
47
Felt Washer
92586
2
A/C Data Decal
48
M6
X
15 Shoulder Bolt
91161
1
19
Heat Riser Box
92364
1
49
Linkage Gov. Lever
91636
1
20
Heat Riser Box Gasket
92363
1
Bellcrank Rod
21
Air CInr. Support Bracket
91367
1
50
Carb. Link. Bellcrank Rod
91637
1
22
M6-1.0
X
10 Taptite Bolt
45756
2
51
A/L Gov. Lever Bellcrank
91649
23
7" Lg. Heat Riser Tube
92182
1
Spring
24
Winter/Summer Lever Assy.
91994
1
52
Breather Tube
91645
1
25
SummerAA/inter Valve
91992
1
53
M6 Flat Washer
22473
4
Guide Plate
54
M6 Flat Washer
22097
2
26
Choke Assy. Bracket
91641
1
55
.261.D. Washer Spring
A4009
1
27
Choke Solenoid Assy.
91306
1
