Generac NP-50G Recreational Vehicle Generator
Drawing No. 92197
REPAIR PARTS BASE AND PULLEYS
ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
1
Mounting Base 92603 1 32 M5 Lock Washer 22152 1
2 Ground Cable 90141 1 33 M5-0.80
X
80mm Screw 77682 1
3 Rubber Mount 46911 4 34 Generator Set Mt. Spring 75242 4
4 3/8"-16x 1/2" Capscrew 25017 8 35 Exh. Base Cover Plate 92203 1
5 Ml0 Lock Washer 46526 10 36 Universal Exh. Adaptor 91146 1
6
M8 Lock Washer 22129 4 37 Fuel Pump 90475 1
7 Rubber Mount Skid 72391 2 38 Fuel Filter 87769 1
8 5/16-18x3-1/2 Safety Bolt 77603 2 39 1/8 Pipe to 1/4 Tube Fitting 87768 1
9 5/16-18 Hex Nut .22259 2 40 Metal Fuel Tube 91634 1
10 M8-1.25 Flanged Lock Nut 52858 6 41 1-1/4 Dia. Exh. Pipe Clamp 96289 1
11 M8-1.25 X 60mm Capscrew 51730 2 42 M6-1.0x16HHCS&Lock 79246 8
12 Belt Tension 29459 2 Washer
13 Spring Cntr. Washer 75215 2 43 Exh. Pipe Gasket 77643 2
14 Nylon Slide 73146 4 44 Foam Tape 29289 10 Ft.
15 Nylon Slide Support 75209 2 45 Grounding Lug 62684 1
16 Exhaust Manifold 91032 1 46 Spring Retainer Washer 75237 4
17 Exhaust Manifold Gasket 90239 1 47 Air Opening Cover 75226 1
18 M8-1.25x65 Socket Hd. 57636 2 48 #10-24
X
.5 Screw 56893 14
Capscrew 49 Foam Slide Pan Gasket 75229 1
19 Collector Pan Gasket 92645 1 50 Slide Pan 75227 1
20 External Cover Plate 90859 1 51 M6 Flat Washer 22473 4
21 Engine Pulley 75224B 1 52 Exhaust Outlet Cover 72384C 1
22 Alt. Pulley 73106B 1 53 M6 Shakeproof 22447 2
23 40" Belt (Poly V4L) 75216 1 Lock Washer
24 Pulley Retainer Washer 49451 1 54 Vinyl Coated Clamp 90088 2
25 3/8"-24 X 1 Socket Hd. 42633 1 55 1/4 Dia. 250mm Fuel Hose 44249B 1
Capscrew (Grade 5) 56 Hose Clamp 48031 2
26 Blower Housing Guide 77017 1 57 5/16-18 Flange Nut 81105 2
27 3/8"-24
X
2-1/2" Capscrew 73118 1 (Special)
28 M6-1.00 X 20 Screw 74906 2 58 Ground Decal 67210 1
29 Fuel Pump Bracket 91123 1 59 M5-0.8 X 10 Taptite Screw 74908 9
30 Blower Housing 72375 1 60 M6-1.0x10 Taptite Screw 45756 9
31 Blower Housing Spacer 73185 1 61 M10 Flat Washer 22131 1
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
21
