¡A ssembly
m
1 Extended Life Generator |
Your generator requires some assembly and is ready for
use after it has been properly serviced with the
recommended oil and fuel.
If you have any problems vvith the assembly of your
generator, please call the generator helpline at
1-800-270-1408.
IMPORTANT: Any attempt to run the unit before it has
been serviced with the recommended oil will result in an
engine failure.
remove gemer / vtor
FROM CARTON
• Set the carton on a rigid flat surface with “This Side Up”
arrows pointing upward.
• Carefully open the top flaps of the shipping carton.
Review “Cold Weather Operation” on page 9.
• Cut down corners at one end of carton from top to
bottom and lay that side of carton down flat.
• Remove all packing material, carton fillers, etc.
• Remove the generator from the shipping carton.
Figure 2 — Install Wheel Kit
INSTALL WHEEL KIT
The wheel kit is designed to greatly improve the portability
of your generator.
NOTE: Wheel kit is not intended for over-the-road use.
You will need a socket wrench with 1/2" or 13mm sockets
and a needle-nose plier to install this kit.
Refer to Figure 2 and install the wheel kit as follows:
• Place the generator on a hard flat surface.
• Stand at the engine end of the generator and gently tilt
the generator forward, high enough to place wooden
blocks beneath the cradle.This will allow you to add the
wheels.
• Slide the axle through the holes in the brackets provided
on the generator cradle.
• Slide one wheel and flat washer on each end of the axle.
Make sure the air inflation valve is outward. Insert both
retaining pins using the needle-nose plier. Remove the
wooden blocks.
• Attach the vibration mounts to the support leg with
30mm capscrews, washers and lock nuts.
