6500XL Extended Life Generator
EXPLODED VIEW AND PARTS LIST — CONTROL PANEL
1
9
2 5
Item Part #
1
2
3
4
5
6
7
8
9
10
11
12
13
A92070GS
23897GS
49226GS
9I526GS
82538GS
82881GS
43I8IGS
43I82GS
904I8GS
75207AGS
75207GS
23365GS
68868GS
Qty Description
I PANEL, Control
4 FLAT WASHER, #10 MS
4 LOCK WASHER, MS
4 SCREW, M5-0.8X 12mm
I SWITCH, Idle Control
4 LOCK WASHER, 7/16"
4 SCREW, M3-0.5 X 10mm
4 LOCK WASHER, M3
1 OUTLET, 12V
2
CIRCUIT BREAKER, 30A
2 CIRCUIT BREAKER, 20A
6 WASHER, #8 Shakeproof
I OUTLET, 120 Volt, 30 Amp
Locking
Item Part #
14 43437GS
15 68759GS
16 43I80GS
17 22264GS
18 5I7I5GS
19 64526GS
20 83970GS
21 64525GS
22 87962GS
23 84335GS
24 84I34GS
25 B92069GS
26 84028GS
Qty Description
I OUTLET, 120V/240V, 30A
Locking
I OUTLET, 120V, 20A Duplex
6 FLAT WASHER, M4
6 LOCK WASHER. #8 M4
6 NUT, M4-0.7 Hex
8 SCREW, #6-32 X 3/8"
I BOARD, System Control
4 STAND-OFF, 3/4" Hex
I CIRCUIT BREAKER. 12V, IOA
I ASSEMBLY.Wire Harness
I GROMMET, Rubber Conn.
I BOX, Control Panel
I TRANSFORMER, Idle Control
