6500XL Extended Life Generator
PARTS LIST - MAIN UNIT
1
NSP
1
ENGINE
43
B4363GS
1
CAP, Fuel Gauge
2
A9253IGS
1
SUPPORT, Support
44
BI998GS
1
TANK, ASM, 7- Gal {Includes
3
A9273IGS
1
SUPPORT Engine & Muffler
Items 41 &42)
4
92247GS
1
HOUSING, Engine Adapter
45
J92039GS
1
SHIELD, Heat
5
92679GGS
1
ASSEMBLY, Rotor (Inclds Item 7)
46
92665GS
1
INSULATION #2-1/4" Thick
6
92681 AGS
1
ASSEMBLY, Stator
47
85000GS
1
CLIP, Insulation
7
65791GS
1
BEARING
48
1435362IGS
1
WIRE, Ground
8
96796GS
1
WASHER, 22,2 O.D. x 3 Thk
49
26850GS
2
WASHER, M6 Shakeproof
9
22I29GS
2
WASHER, M8 Lock
50
39287GS
2
HHCS, M8 - 1.25 x 45
10 86307GS
4
HHMS,5/l6-24x3/4SEMS
51
92982GS
1
DECAL, Danger
11 25254GS
1
HHCS,5/I6-24x9-7/8"
52
I89407GS
2
DECAL, Heat Shield
12 92609GS
2
MOUNTVibration
53
49820GS
2
NUT M8 Nylok
13 82857GS
4
MOUNTVibration
54
22I45GS
4
WASHER, Flat, 5/16 - M8
14 40976GS
2
SCREW, M8 - 1.25 X 20
55
I87I04GS
4
WASHER, Nylon
15 66476GS
2
CAPSCREW, M6 - 1.0
X
12mm
56
BB5586GS
2
HANDLE
16 92532GS
1
BRACKET Muffler
57
B4605GS
2
GRIP
17 22I42GS
2
SCREW, 5/16- 18x3/4"
58
B4I35GS
2
PIN, with Lanyard
18 A7433GS
1
MUFFLER
59
AI87024GS
1
CRADLE
19 90239GS
1
GASKET, Muffler
60
92630GS
1
ASSEMBLY Control Panel
20
8I9I7GS
1
PIN, 4 mm x 10 Roll
61
I89406GS
1
DECAL, Control Pane!
21
B4986GS
1
DECAL, Ground
62
93826GS
1
DECAL, Start Instructions
22
83083 GS
1
SCREEN, Spark Arrester
63
J96068GS
1
SHIELD, Heat
23
22531 GS
2
HHCS,5/I6-I8x 1-3/4"
64
56893GS
5
C
rimpt
ITE, 10-24
X
1/2"
24
I89I60GS
!2
NUT 5/16-18 Serrated Flange
65
A8927GS
1
MANUAL, Engine
25
66825CGS
1
CARRIER, Rear Bearing
66
I894I7GS
1
MANUAL, Owners
26
74908GS
4
TAPTITE, M5-0.8
X
10
67
43438GS
1
PLUG, 240V, 30A 4-Prong
27
86308BGS
4
BOLT M6 -1
X
165 mm Stator
68
37806GS
1
PLUG, I25V,30A 3-Prong
28
65795GS
1
RECTIFIER, Battery Charge
69
70I85GS
1
OIL FILTER
29
66849AGS
1
TAPTITE, M5-0.8
X
20
70
7311 IGS
1
ELEMENTAir Cleaner
30
67022GS
1
GROMMET, Rubber
71
65787GS
1
CABLE, Battery Charge
31
84I32GS
1
ASSEMBLY Power Regulator
72
84882GS
1
WRENCH, Spark Plug
32
66386GS
1
ASSEMBLY Brush Holder
73
72347GS
1
SPARK PLUG
33
66849GS
2
TAPTITE, M5 - 0.8
X
16
74
B4767GS
1
COVER, Storage
34
B487IGS
1
COVER, Bearing Carrier
75
B2I53GS
6
SCREW, Self Driller, 12-14 x 7/8’
35
22769GS
1
WASHER, #10 Int. Shakeproof
76
73054GS
1
DECAL, Fuel Shut Off
36
86494GS
1
SCREW, M6-1.0
X
16 Wing
77
778I6GS
2
DECAL, Caution Hot Muffler
37
86292GS
1
HHCS,#I0 Self Driller
78
20566GS
1
DECAL, 1-800
38
77395GS
4
NUT M6 Flange Lock
79
AB306IGS
2
OIL BOTTLES, 28 oz.
39
83465GS
4
GROMMETTank
40
78831BGS
4
HHCS, M6-1.0x60, SEMS
41
80270GS
1
VALVE,Tank
Optional Accessories Not Included:
42
78299GS
1
BUSHING, Plastic Tank
84883GS
Cord Wrap
