i ^1 /» • rf iSee Figs 2 and 3 |
A
CAUTION-, Dc not short battery ternii-
oais. Before connectinf battery, re*
riiovt!
metal
bracelets,
Wfist^fatch
band I
*1
*
11
, etc,
Positive terminal must be connected
first to prevent sparking from acciden
tal grounding.
•
Remove cardboard packing from seat pan and lift seat
par. to raised position
® Open battery box door,
•
Remove fermina! protective caps and discard.
•
If this batteiy is put into service after month and year
indicated on label (label located between terminals)
charge battery for minimum of one hour at 6-10 amps.
•
First connect RED battery cable to positive (+) terminal
with hex bolt, flat washer, lock washer and hex nut as
shown. Tighten securely.
•
Connect BLACK grounding cable to negative (-) termi
nal with remaining hex bolt, flat washer, lock washer
and hex nut. Tighten securely.
•
Close battery box door.
Open battery box door for:
•
Inspection for secure connections (to tighten hard
ware).
•
Inspection for corrosion.
•
Testing battery.
•
Jumping (if required).
•
Periodic charging .
SEAT
PAN
BATTERY -
BOX DOOR
LOCK
WASHER
FLAT
WASHER
■
