Model 340
PARTS LIST FOR MODEL 340 TILLER
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
786-0036
Belt Cover
26
756-0972
Outer Engine Pulley Half
2
736-3020
FI-Wash. .266" I.D. x .625" O.D.
27
756-0971
Inner Engine Pulley Half
3
710-0599
Hex Wash, Hd. TT-Tap Scr.
28
756-0585
Fl-Puiley 6" Dia.
1/4-20
X
.5" Lg.
30
754-0428
“V’’-Belt
4
712-0392
Hex L-Stop Nut 1/4-28 Thd.
31
748-0350
Pulley Mounting Adapter
5
712-3004A
Hex Flange Top L-Nut
32
736-0112
Bell-Wash. .535" I.D. x 1.5" O.D.
5/16-18 Thd. (Gr. 5)
33
712-3029
Hex Jam Nut 1/2-20 Thd. (Gr. 5)
6
786-0035
Tine Shield
34
738-0102
Shid. Bolt .498" Dia. x 1.45" Lg.
7
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
35
786-0039
Belt Cover Brkt.
8
711-0919
Belt Cover Bolt
38
756-0313
Fl-ldler 2.12" O.D.
10
736-0171
L-Wash, 7/16" I.D.
39
710-0723
Hex Cap Bolt 3/8-16 x 1.25" Lg.
11
710-0380
Hex Bolt 5/16-18
X
1.75" Lg.
40
712-0266
Hex Cent. Jam Nut 3/8-16 Thd.
14
—
Engine
41
750-0892
Spacer .64" I.D. x 2.4" Lg.
15
736-0170
Spec. L-Nut5/16" I.D.
42
686-0011
Tine Idler Brkt. Ass’y.
16
711-0599
Clevis Pin .375" Dia. x 1.75" Lg.
43
756-0199
Fl-ldler 2" O.D.
17
714-0149B
Internal Cotter Pin
44
710-0783
Hex Self-Tap Scr. #8-32 x .38"
18
642-0005
Outer Tine Ass’y.—L.H.
Lg-
642-0004
Outer Tine Ass’y.—R.H.
45
751-0233
Muffler Deflector
(Not Shown)
46
746-0918
N
Clutch Control Cable
19
642-0003
Inner Tine Ass’y.—LH.
48
735-0639
Spark Plug Boot (Optional)
642-0002
Inner Tine Ass’y.—R.H.
50
736-0169
L-Wash. 3/8" I.D.*
(Not Shown)
51
736-0258
FI-Wash. 3/8" I.D. x 1" O.D.
20
686-0009
Chain Case Ass’y. Comp.
52
786-0047
Engine Plate
(Available Only as Comp.
53
786-0053
Tine Shield Support
Ass’y.)
54
712-0240
Hex Nut 7/16-20 Thd.
21
736-0119
L-Wash. 5/16" I.D.*
55
712-3010
Hex Nut 5/16-18 Thd.
k 22
710-0107
Hex Bolt 5/16-24
X.
5" Lg.
56
736-0312
Bearing Retainer Washer
24
710-0191
Hex Bolt 3/8-24 x 1.25" Lg.
‘For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
