PARTS LIST FOR MODEL 390 TILLER
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
710-0874
Hex Bolt 5/16-18
X
1.25" Lg.
26
736-3020
FI-Wash. .266" I.D.
X
.625" O.D.
2
712-3004A
Hex Flange L-Nut 5/16-18 Thd.
27
712-0392
Hex L-Stop Nut 1/4-28 Thd.
(Gr. 5)
28
712-0138
Hex Nut 1/4-28 Thd.
3
786-0004
Tail Piece Brkt. (R.H.)
29
720-0268
Grip-Handle
4
786-0003
Tail Piece Brkt. (L.H.)
30
736-0264
FI-Wash. .344" I.D.
X
.62" O.D.
5
710-0442
Hex Bolt 5/16-18
X
1.5" Lg.
31
736-0140
FI-Wash. .385" I.D. x .62" O.D.
6
712-3004A
Hex Flange L-Nut 5/16-18 Thd.
32
720-0270
Grip-Reverse Lever
(Gr. 5)
33
686-0014
Reverse Handle Ass’y.
7
750-0890
Spacer .32" I.D. x .75" O.D.
34
726-0135
Cap Speed Nut
8
786-0005
Depth Bar
35
741-0475
Plastic Bushing .38" I.D.
9
711-0599
Clevis Pin .375" I.D. x 1.75" Lg.
36
720-0269
Grip-Clutch
10
714-0149B
Internal Cotter Pin
37
747-0815
Clutch Handle Eye Bolt
11
750-0470
Spacer .326" I.D.
X
.47" O.D.
38
686-0008
Clutch Handle Ass’y.
12
750-0885
Spacer .322" I.D. x .44" I.D.
39
710-0189
Hex Bolt 5/16-18x3" Lg.
13
710-0176
Hex Bolt 5/16-18x2.75" Lg.
40
649-0001
Longhorn Handle Ass’y.
14
786-0028
Frame-R.H.
41
746-0919
Clutch Control Cable-Reverse
15
786-0029
Frame-L.H.
42
746-0918
Clutch Control Cable-Forward
16
686-0025
Wheel Hanger Brkt, Ass’y.
43
710-1236
Carr. Bolt 5/16-18
X
1" Lg.
18
738-0213
Shid. Bolt .498" DIa. x1.45" Lg.
(Special)
19
734-1566
Wheel Ass’y. 8" x 1.75"
44
736-0123
FI-Wash. .344" I.D.
X
1.12" O.D.
21
712-3005
Hex Flange L-Nut 3/8-16 Thd.
45
736-0242
Bell-Wash. .345" I.D. x .88" O.D.
(Gr. 5)
46
720-0195
Hand Knob
22
731-1600
N
Handle Cover w/Reverse
47
749-0915
Engine Tubing Brace
23
711-1036
N
Spec, Hex Nut
48
712-0429
Hex Nyloc Nut 5/16-18 Thd.
24
786-0129
N
Cable Guide Brkt.
49
736-0242
Bell-Wash. .345" I.D.
X
.88" O.D.
25
736-0119
L-Wash. 5/16" I.D.*
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
