Model 340
PARTS LIST FOR MODEL 340 TILLER
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 710-0874 Hex Bolt 5/16-18 X 1.25" Lg. 24 786-0129 N Cable Guide Brkt.
2 712-3004A Hex Flange L-Nut 5/16-18 Thd. 25 736-0119 L-Wash. 5/16" I.D.*
(Gr. 5) 26 736-3020 FI-Wash. .266" I.D. x .625" O.D.
3 786-0004 Tail Piece Brkt. (R.H.) 27 712-0392 HexL-Stop Nut 1/4-28 Thd.
4 786-0003 Tail Piece Brkt. (L.H.) 28 712-0138 Hex Nut 1/4-28 Thd.
5 710-0442 Hex Bolt 5/16-18 X 1.5" Lg. 29 720-0268 Grip—Handle
6 712-3004A Hex Flange L-Nut 5/16-18 Thd. 31 736-0140 FI-Wash. .385" I.D. x .62" O.D.
(Gr. 5) 35 741-0475 Plastic Bushing .38" I.D.
7 750-0890 Spacer .32" I.D. x .75" O.D. 36 720-0269 Grip—Clutch
8 786-0005 Depth Bar 37 747-0815 Clutch Handle Eye Bolt
9 711-0599 Clevis Pin .375" I.D. x 1.75" Lg. 38 686-0008 Clutch Handle Ass’y.
10 714-0149B Internal Cotter Pin 39 710-0189 Hex Bolt 5/16-18x3" Lg.
11 750-0470 Spacer .326" I.D. x .47" O.D. 40 649-0001 Longhorn Handle Ass’y.
12 750-0885 Spacer .322" I.D. x .44" O.D. 42 746-0918 N Clutch Control Cable
13 710-0176 Hex Bolt 5/16-18x2.75" Lg. 43 710-1236 Carr. Bolt 5/16-18 X 1" Lg.
14 786-0028 Frame—R.H. (Special)
15 786-0029 Frame—L.H. 44 736-0123 FI-Wash. .344" I.D. x 1.12" O.D.
16 686-0025 Wheel Hanger Brkt. Ass’y- 45 736-0242 Bell-Wash. .345" I.D. x .88" O.D.
18 738-0213 Shid. Bolt .498" Dia. x 1.45" Lg. 46 720-0195 Hand Knob
19 734-1781 Wheel Ass’y. 47 749-0915 Engine Tubing Brace
20 710-3094 Hex Bolt 3/8-16 X 1" Lg. (Gr. 8) 48 712-0429 Hex L-Nut 5/16-18 Thd.
21 712-3005 Hex Flange L-Nut 3/8-16 Thd. 49 736-0242 Bell-Wash. .345" I.D. x .88" O.D.
(Gr. 5) 50 710-3008 Hex Bolt 5/16-18 X. 75" Lg.
22 731-1599 Handle Cover (Gr. 5)
23 711-1036 N Spec. Hex Nut
*For faster service obtain standard nuts, boits and washers iocaily.
if these items cannot be obtained localiy, order by part number
and size as shown on parts list.
6A — Page 7
