PARTS LIST FOR MODEL 216-100A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
1
04248 —312
Engine Bed
2
04126
Inspection Plate
3
710-0128
Hex F-Tapp Scr. #10-32 x .50”
Lg.*
4
—
Engine
5
710-0158
Hex Scr. 5/16-24
X
1.25” Lg.*
6
756-0248
Sheave 3.0” x .50
7
750-0284
Spacer
8
736-0117
FI-Wash. .385” I.D. x .62 O.D.
9
04259
Engine Shaft Spacer
10
736-0169
L-Wash.3/8” Scr.*
11
710-0152
Hex Scr. 3/8-24x1.00” Lg.*
15
710-0259
Hex Sems Scr. 5/16-18 x .62”
Lg.*
17
736-0119
L-Wash. 5/16” Scr.*
18
712-0123
Hex Nut 5/16-24Thd.*
24
712-0181
Hex Top L-Nut 3/8-16 Thd. *
25
710-0600
Hex Wash.-Hd. Self Tapp.
Scr. 5/16-24
X.
50” Lg.
26
04204
Belt Pusher
27
04688
Idler Brkt. Ass’y.
28
738-0183
Shoulder Scr. .500” Dia. x
.215
31
04673
Inner Tine Adapter Ass’y.
32
712-0116
Hex Center L-Nut 3/8-24 Thd.
33
04683
Outer Tine Adapter Ass’y.
34
710-0191
Hex Scr. 3/8-24 x 1.25” Lg. *
35
742-0105
Tine 12”—Left Hand
36
742-0106
Tine 12”—Right Hand
37
736-0169
L-Wash. 3/8” Scr.*
'
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
N
N
38
39
40
41
42
45
46
47
49
50
51
52
53
54
60
61
62
63
64
65
66
67
70
71
712-0241
736-0169
712-0798
710-0539
714-0126
04197 —463
04691 —463
712-0107
716-0119
756-0249
736-0231
736-0119
710-0118
732-0233
712-0107
04196
712-0107
756-0370
736-0300
07353
712-0158
747-0148
754-0196
714-0105
Hex Nut 3/8-24 Thd.‘
L-Wash. 3/8”Scr.*
Hex Nut 3/8-16 Thd.*
Hex Scr. 3/8-24x1.75” Lg.
H.T.
#9 Hi-Pro-Key 3/16
X 3/4”
Dia.
Belt Guard
Mounting PiateAss’y.
Hex Cent. L-Nut V4-20Thd.
Snap Ring з^” Dia. Shaft
Pulley—Double Groove 4.50”
O.D.
FI-Wash. .344x1.125
L-Wash.5/16” Scr.*
Hex Scr. 5/16-18
X
.75” Lg.*
Spring Extension .62 O.D. x
4.94 Lg.
Hex Cent. L-Nut V4-20 Thd.
Hold Down Clamp
Hex Cent. L-Nut V4-20Thd.
Idler Bearing Ass’y.
FI-Wash. .385” I.D.
X
.870”
O.D.
Belt Clip
Hex Cent. L-Nut 5/16-18 Thd
Lower Control Rod
V-Belt
1
/
2
”
X
30” Lg. (Forward
Belt) Fiber “B”
Sq. Key 3/16x3/16x1.00”
Lg-
*For faster service, obtain standard nuts, bolts and washers locally. If these items cannot be
obtained locally, order by part number and size as shown on parts list.
(463—Top Flite Red)
When ordering parts if color or finish is important, use the appropriate color
code shown at left, (e.g Top Flite Red Finish—04624 (463) )
Find u» font in
The tiller is not under warranty by the tiller manufacturer. If repairs or service is
needed on the engine, please contact your nearest authorized engine service outlet. Check
the “Yellow Pages” of your telephone book under “Engines-Qasoline.”
